EPICS Base
7.0.7.0
|
The core data types used by epics. More...
Go to the source code of this file.
Classes | |
struct | epicsString |
!! Don't use this - it may vanish in the future !! More... | |
union | epicsAny |
Union of all types. More... | |
Typedefs | |
typedef char | epicsOldString [MAX_STRING_SIZE] |
!! Don't use this - it may vanish in the future !! More... | |
epicsTypes | |
Architecture Independent Data Types These are sufficient for all our current archs | |
typedef signed char | epicsInt8 |
typedef unsigned char | epicsUInt8 |
typedef short | epicsInt16 |
typedef unsigned short | epicsUInt16 |
typedef int | epicsInt32 |
typedef unsigned int | epicsUInt32 |
typedef long long | epicsInt64 |
typedef unsigned long long | epicsUInt64 |
typedef epicsUInt16 | epicsEnum16 |
typedef float | epicsFloat32 |
typedef double | epicsFloat64 |
typedef epicsInt32 | epicsStatus |
Enumerations | |
enum | epicsBoolean { epicsFalse = 0, epicsTrue = 1 } |
enum | epicsType { epicsInt8T, epicsUInt8T, epicsInt16T, epicsUInt16T, epicsEnum16T, epicsInt32T, epicsUInt32T, epicsFloat32T, epicsFloat64T, epicsStringT, epicsOldStringT } |
Corresponding Type Codes (this enum must start at zero) More... | |
enum | epicsTypeClass { epicsIntC, epicsUIntC, epicsEnumC, epicsFloatC, epicsStringC, epicsOldStringC } |
Variables | |
LIBCOM_API const char * | epicsTypeNames [lastEpicsType+1] |
An array providing the names for each type The enumeration epicsType is an index to this array of type name strings. | |
LIBCOM_API const char * | epicsTypeCodeNames [lastEpicsType+1] |
An array providing the names for each type code The enumeration epicsType is an index to this array of type code name strings. | |
LIBCOM_API const unsigned | epicsTypeSizes [lastEpicsType+1] |
An array providing the sizes for each type The enumeration epicsType is an index to this array of type code name strings. | |
LIBCOM_API const epicsTypeClass | epicsTypeClasses [lastEpicsType+1] |
An array providing the class of each type The enumeration epicsType is an index to this array of type class identifiers. | |
LIBCOM_API const char * | epicsTypeAnyFieldName [lastEpicsType+1] |
An array providing the field name for each type The enumeration epicsType is an index to this array of type code name strings. | |
Definition in file epicsTypes.h.
typedef char epicsOldString[MAX_STRING_SIZE] |
Provided only for backwards compatibility with db_access.h
Definition at line 75 of file epicsTypes.h.
enum epicsType |
Definition at line 108 of file epicsTypes.h.
