EPICS Base
7.0.7.0
|
Functions for interacting with the errlog task. More...
#include <stdarg.h>
#include <stddef.h>
#include <stdio.h>
#include "libComAPI.h"
#include "compilerDependencies.h"
Go to the source code of this file.
Macros | |
#define | errMessage(S, PM) errPrintf(S, __FILE__, __LINE__, " %s\n", PM) |
#define | epicsPrintf errlogPrintf |
#define | epicsVprintf errlogVprintf |
#define | ANSI_ESC_RED "\033[31;1m" |
#define | ANSI_ESC_GREEN "\033[32;1m" |
#define | ANSI_ESC_YELLOW "\033[33;1m" |
#define | ANSI_ESC_BLUE "\033[34;1m" |
#define | ANSI_ESC_MAGENTA "\033[35;1m" |
#define | ANSI_ESC_CYAN "\033[36;1m" |
#define | ANSI_ESC_BOLD "\033[1m" |
#define | ANSI_ESC_RESET "\033[0m" |
#define | ANSI_RED(STR) ANSI_ESC_RED STR ANSI_ESC_RESET |
#define | ANSI_GREEN(STR) ANSI_ESC_GREEN STR ANSI_ESC_RESET |
#define | ANSI_YELLOW(STR) ANSI_ESC_YELLOW STR ANSI_ESC_RESET |
#define | ANSI_BLUE(STR) ANSI_ESC_BLUE STR ANSI_ESC_RESET |
#define | ANSI_MAGENTA(STR) ANSI_ESC_MAGENTA STR ANSI_ESC_RESET |
#define | ANSI_CYAN(STR) ANSI_ESC_CYAN STR ANSI_ESC_RESET |
#define | ANSI_BOLD(STR) ANSI_ESC_BOLD STR ANSI_ESC_RESET |
#define | ERL_ERROR ANSI_RED("ERROR") |
#define | ERL_WARNING ANSI_MAGENTA("WARNING") |
Typedefs | |
typedef void(* | errlogListener )(void *pPrivate, const char *message) |
Enumerations | |
enum | errlogSevEnum { errlogInfo, errlogMinor, errlogMajor, errlogFatal } |
Functions | |
LIBCOM_API int | errlogPrintf (const char *pformat,...) EPICS_PRINTF_STYLE(1 |
LIBCOM_API int LIBCOM_API int | errlogVprintf (const char *pformat, va_list pvar) |
LIBCOM_API int | errlogSevPrintf (const errlogSevEnum severity, const char *pformat,...) EPICS_PRINTF_STYLE(2 |
LIBCOM_API int LIBCOM_API int | errlogSevVprintf (const errlogSevEnum severity, const char *pformat, va_list pvar) |
LIBCOM_API int | errlogMessage (const char *message) |
LIBCOM_API const char * | errlogGetSevEnumString (errlogSevEnum severity) |
LIBCOM_API void | errlogSetSevToLog (errlogSevEnum severity) |
LIBCOM_API errlogSevEnum | errlogGetSevToLog (void) |
LIBCOM_API void | errlogAddListener (errlogListener listener, void *pPrivate) |
LIBCOM_API int | errlogRemoveListeners (errlogListener listener, void *pPrivate) |
LIBCOM_API int | eltc (int yesno) |
LIBCOM_API int | errlogSetConsole (FILE *stream) |
LIBCOM_API int | errlogInit (int bufsize) |
LIBCOM_API int | errlogInit2 (int bufsize, int maxMsgSize) |
LIBCOM_API void | errlogFlush (void) |
LIBCOM_API void | errPrintf (long status, const char *pFileName, int lineno, const char *pformat,...) EPICS_PRINTF_STYLE(4 |
LIBCOM_API void LIBCOM_API int | errlogPrintfNoConsole (const char *pformat,...) EPICS_PRINTF_STYLE(1 |
LIBCOM_API void LIBCOM_API int LIBCOM_API int | errlogVprintfNoConsole (const char *pformat, va_list pvar) |
LIBCOM_API void | errSymLookup (long status, char *pBuf, size_t bufLength) |
Variables | |
LIBCOM_API int | errVerbose |
LIBCOM_API const char * | errlogSevEnumString [] |
This file contains functions for passing error messages with varying severity, registering and un-registering listeners and modifying the log buffer size and max message size.
Some of these functions are similar to the standard C library functions printf and vprintf. For details on the arguments and return codes it is useful to consult any book that describes the standard C library such as The C Programming Language ANSI C Edition
by Kernighan and Ritchie.
Definition in file errlog.h.
#define errMessage | ( | S, | |
PM | |||
) | errPrintf(S, __FILE__, __LINE__, " %s\n", PM) |
errMessage is a macro so it can get the file and line number. It prints the message, the status symbol and string values, and the name of the task which invoked errMessage. It also prints the name of the source file and the line number from which the call was issued.
The message to print should not include a newline as one is added implicitly.
The status code used for the 1st argument is:
S | Status code |
PM | The message to print |
#define epicsPrintf errlogPrintf |
#define epicsVprintf errlogVprintf |
typedef void(* errlogListener)(void *pPrivate, const char *message) |
errlogListener function type.
This is used when adding or removing log listeners in errlogAddListener and errlogRemoveListeners.
enum errlogSevEnum |
LIBCOM_API int errlogPrintf | ( | const char * | pformat, |
... | |||
) |
errlogPrintf is like the printf function provided by the standard C library, except that the output is sent to the errlog task. Unless configured not to, the output will appear on the console as well.
LIBCOM_API int LIBCOM_API int errlogVprintf | ( | const char * | pformat, |
va_list | pvar | ||
) |
errlogVprintf is like the vprintf function provided by the standard C library, except that the output is sent to the errlog task. Unless configured not to, the output will appear on the console as well.
LIBCOM_API int errlogSevPrintf | ( | const errlogSevEnum | severity, |
const char * | pformat, | ||
... | |||
) |
This function is like errlogPrintf except that it adds the severity to the beginning of the message in the form sevr=<value>
where value is one of the enumerated severities in errlogSevEnum. Also the message is suppressed if severity is less than the current severity to suppress.
severity | One of the severity enums from errlogSevEnum |
pformat | The message to log or print |
LIBCOM_API int LIBCOM_API int errlogSevVprintf | ( | const errlogSevEnum | severity, |
const char * | pformat, | ||
va_list | pvar | ||
) |
This function is like errlogVprintf except that it adds the severity to the beginning of the message in the form sevr=<value>
where value is one of the enumerated severities in errlogSevEnum. Also the message is suppressed if severity is less than the current severity to suppress. If epicsThreadIsOkToBlock is true, which is true during iocInit, errlogSevVprintf does NOT send output to the errlog task.
severity | One of the severity enums from errlogSevEnum |
pformat | The message to log or print |
pvar | va_list |
LIBCOM_API int errlogMessage | ( | const char * | message | ) |
Sends message to the errlog task.
message | The message to send |
LIBCOM_API const char* errlogGetSevEnumString | ( | errlogSevEnum | severity | ) |
Gets the string value of severity.
severity | The severity from errlogSevEnum |
LIBCOM_API void errlogSetSevToLog | ( | errlogSevEnum | severity | ) |
Sets the severity to log
severity | The severity from errlogSevEnum |
LIBCOM_API errlogSevEnum errlogGetSevToLog | ( | void | ) |
Gets the current severity to log
LIBCOM_API void errlogAddListener | ( | errlogListener | listener, |
void * | pPrivate | ||
) |
Any code can receive errlog message. This function will add a listener callback.
listener | Function pointer of type errlogListener |
pPrivate | This will be passed as the first argument of listener() |
LIBCOM_API int errlogRemoveListeners | ( | errlogListener | listener, |
void * | pPrivate | ||
) |
This function will remove a listener callback.
listener | Function pointer of type errlogListener |
pPrivate | This will be passed as the first argument of listener() |
LIBCOM_API int eltc | ( | int | yesno | ) |
Normally the errlog system displays all messages on the console. During error message storms this function can be used to suppress console messages. A argument of 0 suppresses the messages, any other value lets messages go to the console.
yesno | (0=No, 1=Yes) |
LIBCOM_API int errlogSetConsole | ( | FILE * | stream | ) |
Sets a new stream to write the messages to
stream | Pointer to file handle |
LIBCOM_API int errlogInit | ( | int | bufsize | ) |
Can be used to initialize the error logging system with a larger buffer. The default buffer size is 1280 bytes.
bufsize | The desired buffer size |
LIBCOM_API int errlogInit2 | ( | int | bufsize, |
int | maxMsgSize | ||
) |
errlogInit2 can be used to initialize the error logging system with a larger buffer and maximum message size. The default buffer size is 1280 bytes, and the default maximum message size is 256.
bufsize | The desired buffer size |
maxMsgSize | The desired max message size |
LIBCOM_API void errlogFlush | ( | void | ) |
Wakes up the errlog task and then waits until all messages are flushed from the queue.
LIBCOM_API void errPrintf | ( | long | status, |
const char * | pFileName, | ||
int | lineno, | ||
const char * | pformat, | ||
... | |||
) |
Routine errPrintf is normally called as follows: errPrintf(status, __FILE__, __LINE__, "\<fmt\>", ...);
Where status is defined as:
status | See above |
pFileName | As shown or NULL if the file name and line number should not be printed. |
lineno | As shown |
pformat | The message to log or print |
The remaining arguments are just like the arguments to the C printf routine. errVerbose determines if the filename and line number are shown.
LIBCOM_API void errSymLookup | ( | long | status, |
char * | pBuf, | ||
size_t | bufLength | ||
) |
Lookup the status code and return the string value in pBuf
status | The status code to lookup |
pBuf | The char buffer to write the string value into |
bufLength | The max size of pBuf |
LIBCOM_API int errVerbose |
Boolean to control whether some messages include more detail
LIBCOM_API const char* errlogSevEnumString[] |
String representation of errlog severity values
