logClient.h File Reference

Client on the IOC that forwards log messages to the log server. More...

#include "libComAPI.h"
#include "osiSock.h"
#include "iocLog.h"

Include dependency graph for logClient.h:

Go to the source code of this file.

Typedefs
typedef void *	logClientId
	Abstract type that represents handle to the log client.

Functions
LIBCOM_API logClientId epicsStdCall	logClientCreate (struct in_addr server_addr, unsigned short server_port)
	Creates a new log client. More...
LIBCOM_API void epicsStdCall	logClientSend (logClientId id, const char *message)
	Log message. More...
LIBCOM_API void epicsStdCall	logClientShow (logClientId id, unsigned level)
	Prints debug information about the log client state. More...
LIBCOM_API void epicsStdCall	logClientFlush (logClientId id)
	Flushes all outstanding messages. More...
LIBCOM_API void epicsStdCall	iocLogPrefix (const char *prefix)
	Set prefix to be sent infront of every log message. More...
LIBCOM_API logClientId epicsStdCall	logClientInit (void)
	DEPRECATED. More...

Detailed Description

Together with the program iocLogServer, a log client provides generic support for logging text messages from an IOC or other program to the log server host machine.

Definition in file logClient.h.

Function Documentation

LIBCOM_API logClientId epicsStdCall logClientCreate	(	struct in_addr	server_addr,
		unsigned short	server_port
	)

Starts a background thread to connect to server and returns immediately. If a connection cannot be established, an error message is printed on the console, but the log client will keep trying to connect in the background. This thread will also periodically (every 5 seconds) flush pending messages out to the server.

Parameters

server_addr	log server IP address
server_port	log server port

Returns

log client handle.

LIBCOM_API void epicsStdCall logClientSend	(	logClientId	id,
		const char *	message
	)

Logs message to log server. Messages are not immediately sent to the log server. Instead they are sent periodically (every 5 seconds), when the cache overflows, or when logClientFlush() is called. If messages can't sent, an error message will be printed to stderr

Parameters

id	log client handle
message	log message

LIBCOM_API void epicsStdCall logClientShow	(	logClientId	id,
		unsigned	level
	)

Print information about the log client's internal state such as, connection status and cache state, to stdout

Parameters

id	log client handle
level	verbosity level. Level range is from 0 to 2

LIBCOM_API void epicsStdCall logClientFlush

(

logClientId

id

)

Immediately sends all outstanding messages to the server

Parameters

id	log client handle

LIBCOM_API void epicsStdCall iocLogPrefix

(

const char *

prefix

)

Sets a prefix to prepend every log message. Can only be set once. If already set, this function call will be ignored

Parameters

prefix

the prefix

LIBCOM_API logClientId epicsStdCall logClientInit

(

void

)

Deprecated:

deprecated interface; retained for backward compatibility
