aaiRecord.h File Reference

Declarations for the aai record type. More...

#include "epicsTypes.h"
#include "link.h"
#include "epicsMutex.h"
#include "ellLib.h"
#include "devSup.h"
#include "epicsTime.h"
#include "callback.h"

Include dependency graph for aaiRecord.h:

Go to the source code of this file.

Classes
struct	aaidset
struct	aaiRecord
	Declaration of aai record type. More...

Macros
#define	HAS_aaidset
#define	AAI_DEVINIT_PASS1   2
#define	aaiPOST_NUM_CHOICES   2
	Number of states defined for menu aaiPOST.

Enumerations
enum	aaiPOST { aaiPOST_Always, aaiPOST_OnChange }
	Enumerated type from menu aaiPOST. More...
enum	aaiFieldIndex {   aaiRecordNAME = 0, aaiRecordDESC = 1, aaiRecordASG = 2, aaiRecordSCAN = 3,   aaiRecordPINI = 4, aaiRecordPHAS = 5, aaiRecordEVNT = 6, aaiRecordTSE = 7,   aaiRecordTSEL = 8, aaiRecordDTYP = 9, aaiRecordDISV = 10, aaiRecordDISA = 11,   aaiRecordSDIS = 12, aaiRecordMLOK = 13, aaiRecordMLIS = 14, aaiRecordBKLNK = 15,   aaiRecordDISP = 16, aaiRecordPROC = 17, aaiRecordSTAT = 18, aaiRecordSEVR = 19,   aaiRecordAMSG = 20, aaiRecordNSTA = 21, aaiRecordNSEV = 22, aaiRecordNAMSG = 23,   aaiRecordACKS = 24, aaiRecordACKT = 25, aaiRecordDISS = 26, aaiRecordLCNT = 27,   aaiRecordPACT = 28, aaiRecordPUTF = 29, aaiRecordRPRO = 30, aaiRecordASP = 31,   aaiRecordPPN = 32, aaiRecordPPNR = 33, aaiRecordSPVT = 34, aaiRecordRSET = 35,   aaiRecordDSET = 36, aaiRecordDPVT = 37, aaiRecordRDES = 38, aaiRecordLSET = 39,   aaiRecordPRIO = 40, aaiRecordTPRO = 41, aaiRecordBKPT = 42, aaiRecordUDF = 43,   aaiRecordUDFS = 44, aaiRecordTIME = 45, aaiRecordUTAG = 46, aaiRecordFLNK = 47,   aaiRecordVAL = 48, aaiRecordPREC = 49, aaiRecordINP = 50, aaiRecordEGU = 51,   aaiRecordHOPR = 52, aaiRecordLOPR = 53, aaiRecordNELM = 54, aaiRecordFTVL = 55,   aaiRecordNORD = 56, aaiRecordBPTR = 57, aaiRecordSIML = 58, aaiRecordSIMM = 59,   aaiRecordSIMS = 60, aaiRecordSIOL = 61, aaiRecordOLDSIMM = 62, aaiRecordSSCN = 63,   aaiRecordSDLY = 64, aaiRecordSIMPVT = 65, aaiRecordMPST = 66, aaiRecordAPST = 67,   aaiRecordHASH = 68 }

Detailed Description

This header was generated from aaiRecord.dbd

Definition in file aaiRecord.h.

Enumeration Type Documentation

enum aaiPOST

Enumerator
aaiPOST_Always	State string "Always".
aaiPOST_OnChange	State string "On Change".

Definition at line 30 of file aaiRecord.h.
