dbUnitTest.h File Reference

Helpers for unittests of process database. More...

#include <stdarg.h>
#include "epicsUnitTest.h"
#include "dbAddr.h"
#include "dbCommon.h"
#include "dbCoreAPI.h"

Include dependency graph for dbUnitTest.h:

Go to the source code of this file.

Typedefs
typedef struct testMonitor	testMonitor

Functions
DBCORE_API void	testdbPrepare (void)
DBCORE_API void	testdbReadDatabase (const char *file, const char *path, const char *substitutions)
DBCORE_API void	testIocInitOk (void)
DBCORE_API void	testIocShutdownOk (void)
DBCORE_API void	testdbCleanup (void)
DBCORE_API void	testdbPutFieldOk (const char *pv, int dbrType,...)
DBCORE_API void	testdbPutFieldFail (long status, const char *pv, int dbrType,...)
DBCORE_API long	testdbVPutField (const char *pv, short dbrType, va_list ap)
DBCORE_API void	testdbGetFieldEqual (const char *pv, int dbrType,...)
DBCORE_API void	testdbVGetFieldEqual (const char *pv, short dbrType, va_list ap)
DBCORE_API void	testdbPutArrFieldOk (const char *pv, short dbrType, unsigned long count, const void *pbuf)
DBCORE_API void	testdbGetArrFieldEqual (const char *pv, short dbfType, long nRequest, unsigned long pbufcnt, const void *pbuf)
DBCORE_API dbCommon *	testdbRecordPtr (const char *pv)
DBCORE_API testMonitor *	testMonitorCreate (const char *pvname, unsigned dbe_mask, unsigned opt)
DBCORE_API void	testMonitorDestroy (testMonitor *)
DBCORE_API void	testMonitorWait (testMonitor *)
DBCORE_API unsigned	testMonitorCount (testMonitor *, unsigned reset)
DBCORE_API void	testSyncCallback (void)
DBCORE_API void	testGlobalLock (void)
DBCORE_API void	testGlobalUnlock (void)

Detailed Description

Author

Michael Davidsaver, Ralph Lange

See Also

Unit testing of record processing

Definition in file dbUnitTest.h.

Function Documentation

DBCORE_API void testdbPrepare

(

void

)

First step in test database setup

See Also

Test skeleton

DBCORE_API void testdbReadDatabase	(	const char *	file,
		const char *	path,
		const char *	substitutions
	)

Read .dbd or .db file

See Also

Test skeleton

DBCORE_API void testIocInitOk

(

void

)

Assert success of iocInit()

See Also

Test skeleton

DBCORE_API void testIocShutdownOk

(

void

)

Shutdown test database processing.

eg. Stops scan threads

See Also

Test skeleton

DBCORE_API void testdbCleanup

(

void

)

Final step in test database cleanup

See Also

Test skeleton

DBCORE_API void testdbPutFieldOk	(	const char *	pv,
		int	dbrType,
			...
	)

Assert that a dbPutField() scalar operation will complete successfully.

testdbPutFieldOk("some.TPRO", DBF_LONG, 1);

See Also

Actions

DBCORE_API void testdbPutFieldFail	(	long	status,
		const char *	pv,
		int	dbrType,
			...
	)

Assert that a dbPutField() operation will fail with a certain S_* code

See Also

Actions

DBCORE_API long testdbVPutField	(	const char *	pv,
		short	dbrType,
		va_list	ap
	)

Assert that a dbPutField() scalar operation will complete successfully.

See Also

Actions

DBCORE_API void testdbGetFieldEqual	(	const char *	pv,
		int	dbrType,
			...
	)

Assert that a dbGetField() scalar operation will complete successfully, with the provided value.

testdbGetFieldEqual("some.TPRO", DBF_LONG, 0);

See Also

Actions

DBCORE_API void testdbVGetFieldEqual	(	const char *	pv,
		short	dbrType,
		va_list	ap
	)

Assert that a dbGetField() scalar operation will complete successfully, with the provided value.

See Also

Actions

DBCORE_API void testdbPutArrFieldOk	(	const char *	pv,
		short	dbrType,
		unsigned long	count,
		const void *	pbuf
	)

Assert that a dbPutField() array operation will complete successfully.

Parameters

pv	a PV name, possibly including filter expression
dbrType	a DBF_* type code (cf. dbfType in dbFldTypes.h)
count	Number of elements in pbuf array
pbuf	Array of values to write

static const epicsUInt32 putval[] = {1,2,3};
testdbPutArrFieldOk("some:wf", DBF_ULONG, NELEMENTS(putval), putval);

See Also

Actions

DBCORE_API void testdbGetArrFieldEqual	(	const char *	pv,
		short	dbfType,
		long	nRequest,
		unsigned long	pbufcnt,
		const void *	pbuf
	)

Parameters

pv	PV name string
dbfType	One of the DBF_* macros from dbAccess.h
nRequest	Number of elements to request from pv
pbufcnt	Number of elements pointed to be pbuf
pbuf	Expected value buffer

Execute dbGet() of nRequest elements and compare the result with pbuf (pbufcnt is an element count). Element size is derived from dbfType.

nRequest > pbufcnt will detect truncation. nRequest < pbufcnt always fails. nRequest ==pbufcnt checks prefix (actual may be longer than expected)

DBCORE_API dbCommon* testdbRecordPtr

(

const char *

pv

)

Obtain pointer to record.

Calls testAbort() on failure. Will never return NULL.

Note

Remember to dbScanLock() when accessing mutable fields.

DBCORE_API testMonitor* testMonitorCreate	(	const char *	pvname,
		unsigned	dbe_mask,
		unsigned	opt
	)

Setup monitoring the named PV for changes

DBCORE_API void testMonitorDestroy

(

testMonitor *

)

Stop monitoring

DBCORE_API void testMonitorWait

(

testMonitor *

)

Return immediately if it has been updated since create, last wait, or reset (count w/ reset=1). Otherwise, block until the value of the target PV is updated.

DBCORE_API unsigned testMonitorCount	(	testMonitor *	,
		unsigned	reset
	)

Return the number of monitor events which have occured since create, or a previous reset (called reset=1). Calling w/ reset=0 only returns the count. Calling w/ reset=1 resets the count to zero and ensures that the next wait will block unless subsequent events occur. Returns the previous count.

DBCORE_API void testSyncCallback

(

void

)

Synchronize the shared callback queues.

Block until all callback queue jobs which were queued, or running, have completed.

DBCORE_API void testGlobalLock

(

void

)

Lock Global convenience mutex for use by test code.

See Also

Global mutex for use by test code.

DBCORE_API void testGlobalUnlock

(

void

)

Unlock Global convenience mutex for use by test code.

See Also

Global mutex for use by test code.
