histogramRecord.h File Reference

Declarations for the histogram record type. More...

#include "epicsTypes.h"
#include "link.h"
#include "epicsMutex.h"
#include "ellLib.h"
#include "devSup.h"
#include "epicsTime.h"
#include "callback.h"

Include dependency graph for histogramRecord.h:

Go to the source code of this file.

Classes
struct	histogramdset
struct	histogramRecord
	Declaration of histogram record type. More...

Macros
#define	HAS_histogramdset
#define	histogramCMD_NUM_CHOICES   4
	Number of states defined for menu histogramCMD.

Enumerations
enum	histogramCMD { histogramCMD_Read, histogramCMD_Clear, histogramCMD_Start, histogramCMD_Stop }
	Enumerated type from menu histogramCMD. More...
enum	histogramFieldIndex {   histogramRecordNAME = 0, histogramRecordDESC = 1, histogramRecordASG = 2, histogramRecordSCAN = 3,   histogramRecordPINI = 4, histogramRecordPHAS = 5, histogramRecordEVNT = 6, histogramRecordTSE = 7,   histogramRecordTSEL = 8, histogramRecordDTYP = 9, histogramRecordDISV = 10, histogramRecordDISA = 11,   histogramRecordSDIS = 12, histogramRecordMLOK = 13, histogramRecordMLIS = 14, histogramRecordBKLNK = 15,   histogramRecordDISP = 16, histogramRecordPROC = 17, histogramRecordSTAT = 18, histogramRecordSEVR = 19,   histogramRecordAMSG = 20, histogramRecordNSTA = 21, histogramRecordNSEV = 22, histogramRecordNAMSG = 23,   histogramRecordACKS = 24, histogramRecordACKT = 25, histogramRecordDISS = 26, histogramRecordLCNT = 27,   histogramRecordPACT = 28, histogramRecordPUTF = 29, histogramRecordRPRO = 30, histogramRecordASP = 31,   histogramRecordPPN = 32, histogramRecordPPNR = 33, histogramRecordSPVT = 34, histogramRecordRSET = 35,   histogramRecordDSET = 36, histogramRecordDPVT = 37, histogramRecordRDES = 38, histogramRecordLSET = 39,   histogramRecordPRIO = 40, histogramRecordTPRO = 41, histogramRecordBKPT = 42, histogramRecordUDF = 43,   histogramRecordUDFS = 44, histogramRecordTIME = 45, histogramRecordUTAG = 46, histogramRecordFLNK = 47,   histogramRecordVAL = 48, histogramRecordNELM = 49, histogramRecordCSTA = 50, histogramRecordCMD = 51,   histogramRecordULIM = 52, histogramRecordLLIM = 53, histogramRecordWDTH = 54, histogramRecordSGNL = 55,   histogramRecordPREC = 56, histogramRecordSVL = 57, histogramRecordBPTR = 58, histogramRecordWDOG = 59,   histogramRecordMDEL = 60, histogramRecordMCNT = 61, histogramRecordSDEL = 62, histogramRecordSIOL = 63,   histogramRecordSVAL = 64, histogramRecordSIML = 65, histogramRecordSIMM = 66, histogramRecordSIMS = 67,   histogramRecordOLDSIMM = 68, histogramRecordSSCN = 69, histogramRecordSDLY = 70, histogramRecordSIMPVT = 71,   histogramRecordHOPR = 72, histogramRecordLOPR = 73 }

Detailed Description

This header was generated from histogramRecord.dbd

Definition in file histogramRecord.h.

Enumeration Type Documentation

enum histogramCMD

Enumerator
histogramCMD_Read	State string "Read".
histogramCMD_Clear	State string "Clear".
histogramCMD_Start	State string "Start".
histogramCMD_Stop	State string "Stop".

Definition at line 30 of file histogramRecord.h.
