Declarations for the stringout record type. More...
#include "epicsTypes.h"
#include "link.h"
#include "epicsMutex.h"
#include "ellLib.h"
#include "devSup.h"
#include "epicsTime.h"
#include "callback.h"
Go to the source code of this file.
Classes | |
struct | stringoutdset |
struct | stringoutRecord |
Declaration of stringout record type. More... | |
Macros | |
#define | HAS_stringoutdset |
#define | stringoutPOST_NUM_CHOICES 2 |
Number of states defined for menu stringoutPOST. | |
Enumerations | |
enum | stringoutPOST { stringoutPOST_OnChange, stringoutPOST_Always } |
Enumerated type from menu stringoutPOST. More... | |
enum | stringoutFieldIndex { stringoutRecordNAME = 0, stringoutRecordDESC = 1, stringoutRecordASG = 2, stringoutRecordSCAN = 3, stringoutRecordPINI = 4, stringoutRecordPHAS = 5, stringoutRecordEVNT = 6, stringoutRecordTSE = 7, stringoutRecordTSEL = 8, stringoutRecordDTYP = 9, stringoutRecordDISV = 10, stringoutRecordDISA = 11, stringoutRecordSDIS = 12, stringoutRecordMLOK = 13, stringoutRecordMLIS = 14, stringoutRecordBKLNK = 15, stringoutRecordDISP = 16, stringoutRecordPROC = 17, stringoutRecordSTAT = 18, stringoutRecordSEVR = 19, stringoutRecordAMSG = 20, stringoutRecordNSTA = 21, stringoutRecordNSEV = 22, stringoutRecordNAMSG = 23, stringoutRecordACKS = 24, stringoutRecordACKT = 25, stringoutRecordDISS = 26, stringoutRecordLCNT = 27, stringoutRecordPACT = 28, stringoutRecordPUTF = 29, stringoutRecordRPRO = 30, stringoutRecordASP = 31, stringoutRecordPPN = 32, stringoutRecordPPNR = 33, stringoutRecordSPVT = 34, stringoutRecordRSET = 35, stringoutRecordDSET = 36, stringoutRecordDPVT = 37, stringoutRecordRDES = 38, stringoutRecordLSET = 39, stringoutRecordPRIO = 40, stringoutRecordTPRO = 41, stringoutRecordBKPT = 42, stringoutRecordUDF = 43, stringoutRecordUDFS = 44, stringoutRecordTIME = 45, stringoutRecordUTAG = 46, stringoutRecordFLNK = 47, stringoutRecordVAL = 48, stringoutRecordOVAL = 49, stringoutRecordDOL = 50, stringoutRecordOMSL = 51, stringoutRecordOUT = 52, stringoutRecordMPST = 53, stringoutRecordAPST = 54, stringoutRecordSIOL = 55, stringoutRecordSIML = 56, stringoutRecordSIMM = 57, stringoutRecordSIMS = 58, stringoutRecordOLDSIMM = 59, stringoutRecordSSCN = 60, stringoutRecordSDLY = 61, stringoutRecordSIMPVT = 62, stringoutRecordIVOA = 63, stringoutRecordIVOV = 64 } |
This header was generated from stringoutRecord.dbd
Definition in file stringoutRecord.h.
enum stringoutPOST |
Enumerator | |
---|---|
stringoutPOST_OnChange |
State string "On Change". |
stringoutPOST_Always |
State string "Always". |
Definition at line 29 of file stringoutRecord.h.
