dbLink.h File Reference

Link Support API. More...

#include "link.h"
#include "dbCoreAPI.h"
#include "epicsTypes.h"
#include "epicsTime.h"
#include "dbAddr.h"
#include "dbChannel.h"

Include dependency graph for dbLink.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	lset
	Link Support Entry Table. More...

Macros
#define	dbGetSevr(link, sevr)   dbGetAlarm(link, NULL, sevr)
#define	dbGetAlarmMsg(LINK, STAT, SEVR, BUF, BUFLEN)   dbGetAlarmMsg(LINK, STAT, SEVR, BUF, BUFLEN)
#define	dbGetTimeStampTag(LINK, STAMP, TAG)   dbGetTimeStampTag(LINK, STAMP, TAG)

Typedefs
typedef long(*	dbLinkUserCallback )(struct link *plink, void *priv)
	callback routine for locked link operations More...

Functions
DBCORE_API const char *	dbLinkFieldName (const struct link *plink)
DBCORE_API void	dbInitLink (struct link *plink, short dbfType)
DBCORE_API void	dbAddLink (struct dbLocker *locker, struct link *plink, short dbfType, dbChannel *ptarget)
DBCORE_API void	dbLinkOpen (struct link *plink)
DBCORE_API void	dbRemoveLink (struct dbLocker *locker, struct link *plink)
DBCORE_API int	dbLinkIsDefined (const struct link *plink)
DBCORE_API int	dbLinkIsConstant (const struct link *plink)
DBCORE_API int	dbLinkIsVolatile (const struct link *plink)
DBCORE_API long	dbLoadLink (struct link *plink, short dbrType, void *pbuffer)
DBCORE_API long	dbLoadLinkArray (struct link *, short dbrType, void *pbuffer, long *pnRequest)
DBCORE_API long	dbGetNelements (const struct link *plink, long *pnElements)
DBCORE_API int	dbIsLinkConnected (const struct link *plink)
DBCORE_API int	dbGetLinkDBFtype (const struct link *plink)
DBCORE_API long	dbTryGetLink (struct link *, short dbrType, void *pbuffer, long *nRequest)
DBCORE_API long	dbGetLink (struct link *, short dbrType, void *pbuffer, long *options, long *nRequest)
DBCORE_API long	dbGetControlLimits (const struct link *plink, double *low, double *high)
DBCORE_API long	dbGetGraphicLimits (const struct link *plink, double *low, double *high)
DBCORE_API long	dbGetAlarmLimits (const struct link *plink, double *lolo, double *low, double *high, double *hihi)
DBCORE_API long	dbGetPrecision (const struct link *plink, short *precision)
DBCORE_API long	dbGetUnits (const struct link *plink, char *units, int unitsSize)
DBCORE_API long	dbGetAlarm (const struct link *plink, epicsEnum16 *status, epicsEnum16 *severity)
DBCORE_API long	dbGetAlarmMsg (const struct link *plink, epicsEnum16 *status, epicsEnum16 *severity, char *msgbuf, size_t msgbuflen)
DBCORE_API long	dbGetTimeStamp (const struct link *plink, epicsTimeStamp *pstamp)
DBCORE_API long	dbGetTimeStampTag (const struct link *plink, epicsTimeStamp *pstamp, epicsUTag *ptag)
DBCORE_API long	dbPutLink (struct link *plink, short dbrType, const void *pbuffer, long nRequest)
DBCORE_API void	dbLinkAsyncComplete (struct link *plink)
DBCORE_API long	dbPutLinkAsync (struct link *plink, short dbrType, const void *pbuffer, long nRequest)
DBCORE_API void	dbScanFwdLink (struct link *plink)
DBCORE_API long	dbLinkDoLocked (struct link *plink, dbLinkUserCallback rtn, void *priv)
DBCORE_API long	dbLoadLinkLS (struct link *plink, char *pbuffer, epicsUInt32 size, epicsUInt32 *plen)
DBCORE_API long	dbGetLinkLS (struct link *plink, char *pbuffer, epicsUInt32 buffer_size, epicsUInt32 *plen)
DBCORE_API long	dbPutLinkLS (struct link *plink, char *pbuffer, epicsUInt32 len)

Detailed Description

Link support run-time API, all link types provide an lset which is used by the IOC database to control and operate the link. This file also declares the dbLink routines that IOC, record and device code can call to perform link operations.

Definition in file dbLink.h.

Typedef Documentation

typedef long(* dbLinkUserCallback)(struct link *plink, void *priv)

Called by the lset::doLocked method to permit multiple link operations while the link instance is locked.

Parameters

plink	the link
priv	context for the callback routine

Definition at line 49 of file dbLink.h.

Function Documentation

DBCORE_API long dbGetAlarmMsg	(	const struct link *	plink,
		epicsEnum16 *	status,
		epicsEnum16 *	severity,
		char *	msgbuf,
		size_t	msgbuflen
	)

Get link alarm and message string. To ensure the complete message string is copied, ensure

msgbuflen >= sizeof (dbCommon::amsg)

. A trailing nil will be added whenever

msgbuflen > 0

.

Since

7.0.6

DBCORE_API long dbGetTimeStampTag	(	const struct link *	plink,
		epicsTimeStamp *	pstamp,
		epicsUTag *	ptag
	)

Since

7.0.6
