Subject: RE: [EXTERNAL] Basics: mbbi record
From: "Pearson, Matthew R. via Tech-talk" <tech-talk at aps.anl.gov>
To: William Kirstaedter <kirstaedter at fhi-berlin.mpg.de>
Cc: "tech-talk at aps.anl.gov" <tech-talk at aps.anl.gov>
Date: Tue, 27 Jul 2021 15:25:13 +0000



Hi,



I think you also need to initialize the value fields (ZRVL, ONVL, etc), as well as the strings.



Cheers,

Matt



From: Tech-talk <tech-talk-bounces at aps.anl.gov> On Behalf Of William Kirstaedter via Tech-talk
Sent: Tuesday, July 27, 2021 11:09 AM
To: tech-talk at aps.anl.gov
Subject: [EXTERNAL] Basics: mbbi record



Hi all,

I need some help with basic EPICS records, because I'm just getting "Illegal Value"...

I'm reading from a Modbus TCP device, 16 bit.
Each Bit represents an Input Pin which can be HIGH or LOW. Very Basic.

Bit 7 is 1 because the Input on Pin 7 is HIGH.
-> Decimal Value is 128.

RVAL of the mbbi record is 128.
I read this as "modbus works, correct value recieved"

mbbi should now convert the value und put something in VAL.
it does not.

heres my IOCs output:

epics> dbpr FHIFEL:TBEN1:IO,7

ACKS: NO_ALARM      ACKT: YES           AFTC: 0             AFVL: 0

AMSG:               ASG :               ASP : PTR (nil)

BKLNK: ELL 0 [(nil) .. (nil)]           BKPT: 00            COSV: NO_ALARM

DESC:               DISA: 0             DISP: 0             DISS: NO_ALARM

DISV: 1             DPVT: PTR 0x5586f8fc5ac0

DSET: PTR 0x7f008bcd5260                DTYP: asynInt32     EIST: Port5 DI

EISV: NO_ALARM      EIVL: 0x0           ELST: Port6 DXP     ELSV: NO_ALARM

ELVL: 0x0           EVNT:               FFST: Port8 DXP     FFSV: NO_ALARM

FFVL: 0x0           FLNK: CONSTANT      FRST: Port3 DI      FRSV: NO_ALARM

FRVL: 0x0           FTST: Port8 DI      FTSV: NO_ALARM      FTVL: 0x0

FVST: Port3 DXP     FVSV: NO_ALARM      FVVL: 0x0

INP : INST_IO @asyn(read_IO 0) INT32_LE LALM: 65535         LCNT: 0

LSET: PTR 0x5586f8fd0430                MASK: 65535

MLIS: ELL 0 [(nil) .. (nil)]            MLOK: d0 09 fd f8 86 55 00 00

MLST: 65535         NAME: FHIFEL:TBEN1:IO                   NAMSG:

NIST: Port5 DXP     NISV: NO_ALARM      NIVL: 0x0           NOBT: 16

NSEV: NO_ALARM      NSTA: NO_ALARM      OLDSIMM: NO         ONST: Port1 DXP

ONSV: NO_ALARM      ONVL: 0x0           ORAW: 128           PACT: 0

PHAS: 0             PINI: NO            PPN : PTR (nil)     PPNR: PTR (nil)

PRIO: LOW           PROC: 0             PUTF: 0

RDES: PTR 0x5586f8f7e5e0                RPRO: 0

RSET: PTR 0x7f008bc1b120                RVAL: 128           SCAN: 1 second

SDEF: 1             SDIS: CONSTANT      SDLY: -1            SEVR: NO_ALARM

SHFT: 0             SIML: CONSTANT      SIMM: NO            SIMPVT: PTR (nil)

SIMS: NO_ALARM      SIOL: CONSTANT      SPVT: PTR 0x5586f8fdde00

SSCN: <nil>         STAT: NO_ALARM      SVAL: 0             SVST: Port4 DXP

SVSV: NO_ALARM      SVVL: 0x0           SXST: Port4 DI      SXSV: NO_ALARM

SXVL: 0x0           TEST: Port6 DI      TESV: NO_ALARM      TEVL: 0x0

THST: Port2 DXP     THSV: NO_ALARM      THVL: 0x0

TIME: 2021-07-27 17:05:46.233100930     TPRO: 0             TSE : 0

TSEL: CONSTANT      TTST: Port7 DXP     TTSV: NO_ALARM      TTVL: 0x0

TVST: Port7 DI      TVSV: NO_ALARM      TVVL: 0x0           TWST: Port2 DI

TWSV: NO_ALARM      TWVL: 0x0           UDF : 0             UDFS: INVALID

UNSV: NO_ALARM      UTAG: 0             VAL : 65535         ZRST: Port1 DI

ZRSV: NO_ALARM      ZRVL: 0x0

epics>

and the record:

record(mbbi, "$(P):$(R):$(Q)") {

    field(DTYP, "asynInt32")

    field(INP,"@asyn($(PORT) $(OFFSET)) INT32_LE")

    field(SCAN, "1 second")

    field(MASK, "0")

    field(NOBT, "16")

    field(ZRST, "Port1 DI")

    field(ONST, "Port1 DXP")

    field(TWST, "Port2 DI")

    field(THST, "Port2 DXP")

    field(FRST, "Port3 DI")

    field(FVST, "Port3 DXP")

    field(SXST, "Port4 DI")

    field(SVST, "Port4 DXP")

    field(EIST, "Port5 DI")

    field(NIST, "Port5 DXP")

    field(TEST, "Port6 DI")

    field(ELST, "Port6 DXP")

    field(TVST, "Port7 DI")

    field(TTST, "Port7 DXP")

    field(FTST, "Port8 DI")

    field(FFST, "Port8 DXP")

}

can anyone tell me why its not converting the RVAL?

thanks,

William

--

William Kirstaedter (PP&B)

Fritz-Haber-Institut der MPG

Faradayweg 4-6

14195 Berlin

Tel: 030 8413 5405

Mail: kirstaedter at fhi-berlin.mpg.de
