It works, thanks.

Somewhat unintuitive I'd say...

but maybe I just got distracted by my corner case which has an exact bit to pin representation.

William Kirstaedter (PP&B)	Fritz-Haber-Institut der MPG
Faradayweg 4-6	14195 Berlin
Tel: 030 8413 5405	Mail: kirstaedter at fhi-berlin.mpg.de

I'll retry.

You say that I need to put "128" in SVVL ?

William Kirstaedter (PP&B)	Fritz-Haber-Institut der MPG
Faradayweg 4-6	14195 Berlin
Tel: 030 8413 5405	Mail: kirstaedter at fhi-berlin.mpg.de

Am 27.07.2021 um 17:25 schrieb Ralph Lange via Tech-talk:

See also https://epics.anl.gov/base/R7-0/5-docs/mbbiRecord.html

The mbbi works like an enum type, where each of the up to 16 enum choices is related to exactly one raw value.

Your database only sets the string representations and doesn't set the matching raw values.

Cheers,
~Ralph
