Subject: Re: Imaging Source USB Camera
From: Mark Rivers via Tech-talk <tech-talk at aps.anl.gov>
To: William Kirstaedter <kirstaedter at fhi-berlin.mpg.de>
Cc: "tech-talk at aps.anl.gov" <tech-talk at aps.anl.gov>
Date: Wed, 6 Oct 2021 12:05:12 +0000
> are all products from FLIR supported


Yes, they are all GenICam compliant and can be used with either the ADAravis (Linux) or ADSpinnaker (Linux and Windows) drivers in areaDetector.  I would suggest the Blackfly S models, which are available in both USB 3.0 and GigE versions.


Mark



________________________________
From: William Kirstaedter <kirstaedter at fhi-berlin.mpg.de>
Sent: Wednesday, October 6, 2021 6:50 AM
To: Mark Rivers
Cc: tech-talk at aps.anl.gov
Subject: Re: Imaging Source USB Camera


thanks,

the camera is already here. "old stuff".

are all products from FLIR supported ?

- W

[cid:[email protected]]
William Kirstaedter (PP&B)      Fritz-Haber-Institut der MPG
Faradayweg 4-6  14195 Berlin
Tel: 030 8413 5405      Mail: kirstaedter at fhi-berlin.mpg.de<mailto:kirstaedter at fhi-berlin.mpg.de>
Am 06.10.2021 um 13:44 schrieb Mark Rivers:

Hi William,


There is no mention on their Web site that the camera is GenICam compliant.  If it were then you could use ADAravis on Linux.  It appears that their software library only works on Windows.


Do you already have this camera, and if so it there any reason it could not be replaced with another one?  You could replace it for less than $400 with a much better performance FLIR camera.  That is much less than the cost of writing an EPICS driver for an unsupported camera.


Mark



________________________________
From: Tech-talk <tech-talk-bounces at aps.anl.gov><mailto:tech-talk-bounces at aps.anl.gov> on behalf of William Kirstaedter via Tech-talk <tech-talk at aps.anl.gov><mailto:tech-talk at aps.anl.gov>
Sent: Wednesday, October 6, 2021 6:22 AM
To: EPICS tech-talk
Subject: Imaging Source USB Camera


Hi,

just wanted to check;

has anyone already integrated the following camera into EPICS ?

"Imaging Source DMK 41AU02"

its a simple greyscale USB 2.0 Camera.

there is a C library available: https://www.theimagingsource.com/products/industrial-cameras/usb-2.0-monochrome/dmk41au02/

any thoughts about this thing?

--
[cid:[email protected]]
William Kirstaedter (PP&B)      Fritz-Haber-Institut der MPG
Faradayweg 4-6  14195 Berlin
Tel: 030 8413 5405      Mail: kirstaedter at fhi-berlin.mpg.de<mailto:kirstaedter at fhi-berlin.mpg.de><mailto:kirstaedter at fhi-berlin.mpg.de><mailto:kirstaedter at fhi-berlin.mpg.de>
