TL;DR: it now works with Heinz' suggestion:

longer explanation:

we have multiple small labs with own, dedicated networks, that NAT outgoing traffic.
but, all of them utilize the same private network: 10.0.0.0/23, since I set them up via script.

so routing is not an option.

next idea was to translate the recceivers broadcast signal into the private lab network, via iptables, kind of a reverse NAT if you will.

but as it turned out, iptables doesnt handle broadcast packets so I switched to socat which does.

since the reccasters in the IOCs only respond to the address in the 16byte message, the response never got through...

but now, with the correct and dedicated IP of the channelfinder server in it, it works perfectly. :)

by the way: FF FF FF FF as an IP address doesnt make sense to me anyways.
in my eyes, the reccaster should either broadcast its first IP address or a configured one?

 - William

William Kirstaedter (PP&B)	Fritz-Haber-Institut der MPG
Faradayweg 4-6	14195 Berlin
Tel: 030 8413 5405	Mail: kirstaedter at fhi-berlin.mpg.de

Hallo Han,
thanks for the hint. But this only works if the computer system also has a “leg” (network connection)  into the respective networks?

We also have something like this for the FEL network, for example. But otherwise there are always gateway computers between the individual experiment networks und the main-net.
However, since we are routing out of the experiment machines into our main-net, I'll try my hand at modifying announce.py.

tcpaddr='\xff\xff\xff\xff’ -> tcpaddr='\x8d\x0e\x8c\x62’  (141.14.140.98)

Heinz

On 24. Apr 2022, at 02:43, Han Lee <jeonglee at lbl.gov> wrote:

Hi Heinz,

Could you try to add your IOC address subnets into the recceiver server configuration as addr_list?

https://github.com/jeonghanlee/RecSync-env/blob/7b9fbc794ec8e4ae36349593780f9dcd00d142a0/site-template/recsync.conf.in#L16

Multiple IOCs just see the resync server (Not CF - elasticsearch - server) without issues.

For example, you can add each subnet where your IOCs are running, such as

10.10.11.255:5049, 10.10.48.255:5049, ..................................

I hope this is what you are looking for. Or I completely misunderstand your description.

Best,
Han


On Fri, Apr 22, 2022 at 11:52 AM Heinz Junkes via Tech-talk <tech-talk at aps.anl.gov> wrote:
Hi,

we need to route the announcements from our central Channelfinder server to a subnet so that the
recasters on the IOCs in the subnet can send their PV information to the server.

Unfortunately, the announcement package does not contain the IP of the server but FF:FF:FF:FF.

root@priscilla:~# socat -ls -u -v -x UDP4-RECVFROM:5049,broadcast,fork,bind=141.14.143.255 UDP4-SENDTO:10.0.1.255:5049,broadcast

2022/04/22 17:22:18.879313  length=16 from=0 to=15

52 43 00 00 ff ff ff ff 84 81 00 00 61 bf c1 23  RC..........a..#

Gruss Heinz




--
Jeong Han Lee, Dr.rer.nat
Staff Scientist and Engineer
Lawrence Berkeley National Laboratory
1 Cyclotron Road Mailstop 46R0161
Berkeley, CA 94720, United States
Tel :+1-510-486-6163
Cell:+1-510-384-3868
