Subject: Re: Imaging Source USB Camera
From: "Wlodek, Jakub via Tech-talk" <tech-talk at aps.anl.gov>
To: Mark Rivers <rivers at cars.uchicago.edu>, William Kirstaedter <kirstaedter at fhi-berlin.mpg.de>
Cc: "tech-talk at aps.anl.gov" <tech-talk at aps.anl.gov>
Date: Wed, 6 Oct 2021 14:58:38 +0000
Hi William,

You can use the ADUVC driver to use a typical USB webcam with EPICS/areaDetector. Any device that supports the UVC protocl would work, here are some examples:


I have used this driver with raspberry Pi devices in the past.

It's even possible that your original camera would work, although I am not sure if it uses the UVC protocol. It may be worth asking the vendor if that is supported.

Best,
Jakub

From: Tech-talk <tech-talk-bounces at aps.anl.gov> on behalf of William Kirstaedter via Tech-talk <tech-talk at aps.anl.gov>
Sent: Wednesday, October 6, 2021 10:54 AM
To: Mark Rivers <rivers at cars.uchicago.edu>
Cc: tech-talk at aps.anl.gov <tech-talk at aps.anl.gov>
Subject: Re: Imaging Source USB Camera


I think the performance requirements for a Blackfly S are too high for a simple Raspberry Pi 3?

are there any slow, standard cameras that could work with EPICS?

William Kirstaedter (PP&B) Fritz-Haber-Institut der MPG
Faradayweg 4-6 14195 Berlin
Tel: 030 8413 5405 Mail: kirstaedter at fhi-berlin.mpg.de
Am 06.10.2021 um 14:05 schrieb Mark Rivers:
are all products from FLIR supported

Yes, they are all GenICam compliant and can be used with either the ADAravis (Linux) or ADSpinnaker (Linux and Windows) drivers in areaDetector.  I would suggest the Blackfly S models, which are available in both USB 3.0 and GigE versions.


Mark



________________________________
From: William Kirstaedter <kirstaedter at fhi-berlin.mpg.de>
Sent: Wednesday, October 6, 2021 6:50 AM
To: Mark Rivers
Cc: tech-talk at aps.anl.gov
Subject: Re: Imaging Source USB Camera


thanks,

the camera is already here. "old stuff".

are all products from FLIR supported ?

- W

[cid:[email protected]]
William Kirstaedter (PP&B)      Fritz-Haber-Institut der MPG
Faradayweg 4-6  14195 Berlin
Tel: 030 8413 5405      Mail: kirstaedter at fhi-berlin.mpg.de<mailto:kirstaedter at fhi-berlin.mpg.de>
Am 06.10.2021 um 13:44 schrieb Mark Rivers:

Hi William,


There is no mention on their Web site that the camera is GenICam compliant.  If it were then you could use ADAravis on Linux.  It appears that their software library only works on Windows.


Do you already have this camera, and if so it there any reason it could not be replaced with another one?  You could replace it for less than $400 with a much better performance FLIR camera.  That is much less than the cost of writing an EPICS driver for an unsupported camera.


Mark



________________________________
From: Tech-talk <tech-talk-bounces at aps.anl.gov><mailto:tech-talk-bounces at aps.anl.gov> on behalf of William Kirstaedter via Tech-talk <tech-talk at aps.anl.gov><mailto:tech-talk at aps.anl.gov>
Sent: Wednesday, October 6, 2021 6:22 AM
To: EPICS tech-talk
Subject: Imaging Source USB Camera


Hi,

just wanted to check;

has anyone already integrated the following camera into EPICS ?

"Imaging Source DMK 41AU02"

its a simple greyscale USB 2.0 Camera.

there is a C library available: https://www.theimagingsource.com/products/industrial-cameras/usb-2.0-monochrome/dmk41au02/

any thoughts about this thing?

--
[cid:[email protected]]
William Kirstaedter (PP&B)      Fritz-Haber-Institut der MPG
Faradayweg 4-6  14195 Berlin
Tel: 030 8413 5405      Mail: kirstaedter at fhi-berlin.mpg.de<mailto:kirstaedter at fhi-berlin.mpg.de><mailto:kirstaedter at fhi-berlin.mpg.de><mailto:kirstaedter at fhi-berlin.mpg.de>
